·Braiding Material: Nitinol,Stainless Steel,Cobalt Chromium,DFTWire,PLLA,Magnesium,etc
·Material size: Starts from Φ0.0125mm/0.0005″
·Braiding PPl: 10-300 PPl,with variable PPI braiding,gradual and abrupt change
·Output: 480 picks/min

Basic information
Carrier Number：48
Size：L2500*W1000*H2100mm
Weight：700KG
Total Power：4KW
Table Speed：≦320rpm
Braiding Pattern：
48 Carrier: 1-2&2-2 24 Carrier: 1-1
16 Carrier: 1-2&2-2 8 Carrier: 1-1
